Product Summary
The LA75676NVA-TLM-E is an NTSC intercarrier VIF/SIF IC that adopts a semi-adjustment-free structure. In particular, it uses VCO adjustment to make AFT adjustment unnecessary and thus simplifies the overall adjustment process.
Parametrics
Absolute maximum ratings: (1)Maximum supply voltage, VCC max: 6V; (2)Circuit voltage, V13, V17: VCC V; (3)Circuit current: I6: -3mA; I10: -10mA; I14: -2mA; (4)Allowable power dissipation, Pd max: 400mW; (5)Operating temperature, Topr: –20 to +70℃; (6)Storage temperature, Tstg: –55 to +150℃.
Features
Features: (1)No AFT or SIF coils are used, thus eliminating adjustments; (2)Excellent audio performance due to the built-in buzz; (3)canceller; (4)VCC = 5 V and a low power dissipation of 250 mW.
