P89V51RD2FA

80C51 microcontroller, 64 kB Flash, 1024 bytes

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~2.23 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.00~2.23

PartNumber:: P89V51RD2FA

Brand:: | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Cheongtai's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-05-08

From Other Seller

Part Number:P89V51RD2FA
US $2.00 - 2.23
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The P89V51RD2FA is an 80C51 microcontroller with 64 kB Flash and 1024 bytes of data RAM. A key feature of the P89V51RD2FA is its X2 mode option.

Parametrics

Absolute maximum ratings: (1)operating bias ambient temperature: -55 to +125 ℃; (2)Tstg storage temperature range: -65 to +150 ℃; (3)VEA voltage on EA pin to VSS: -0.5 to 14 V; (4)Vn DC voltage on any pin to ground potential: -0.5 to VDD + 0.5 V; (5)Vit transient voltage (<20 ns) on any other pin to VSS: -1.0 to VDD + 1.0 V; (6)IOL(I/O) maximum IOL per I/O pins P1.5, P1.6, P1.7: 20 mA; (7)IOL(I/O) maximum IOL per I/O for all other pins: 15 mA; (8)Ptot(pack) total power dissipation per package Tamb = 25 ℃: 1.5 W.

Features

Features: (1)80C51 Central Processing Unit; (2)5 V Operating voltage from 0 to 40 MHz; (3)64 kB of on-chip Flash program memory with ISP (In-System Programming) and IAP (In-Application Programming); (4)Supports 12-clock (default) or 6-clock mode selection via software or ISP; (5)SPI (Serial Peripheral Interface) and enhanced UART; (6)PCA (Programmable Counter Array) with PWM and Capture/Compare functions; (7)Four 8-bit I/O ports with three high-current Port 1 pins (16 mA each); (8)Three 16-bit timers/counters; (9)Programmable Watchdog timer (WDT); (10)Eight interrupt sources with four priority levels; (11)Second DPTR register; (12)Low EMI mode (ALE inhibit); (13)TTL- and CMOS-compatible logic levels.
