Product Summary
The NB100LVEP91MNG is a triple any level positive input to NECL output translator. The NB100LVEP91MNG accepts LVPECL, LVTTL, LVCMOS, HSTL, CML or LVDS signals, and translates them to differential LVNECL output signals (-2.5 V / -3.3 V).
Parametrics
NB100LVEP91MNG absolute maximum ratings: (1)VCC, Positive Power Supply: 3.8 to 0 V; (2)VEE, Negative Power Supply: -3.8 to 0 V; (3)VI, Positive Input Voltage: 3.8 to 0 V; (4)VOP, Operating Voltage: 7.6 to 0 V; (5)Iout, Output Current: 50mA; (6)IBB, PECL VBB Sink/Source: ± 0.5 mA; (7)TA, Operating Temperature Range: -40 to +85℃; (8)Tstg, Storage Temperature Range: -65 to +150℃; (9)θJA, Thermal Resistance: 90℃/W; (10)θJA, Thermal Resistance: 37℃/W.
Features
NB100LVEP91MNG features: (1)Maximum Input Clock Frequency > 2.0 GHz Typical; (2)Maximum Input Data Rate > 2.0 Gb/s Typical; (3)500 ps Typical Propagation Delay; (4)Operating Range: VCC = 2.375 V to 3.8 V; VEE = -2.375 V to 3.8 V; GND = 0 V; (5)Q Output will Default LOW with Inputs Open or at GND; (6)Pb-Free Packages are Available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 NB100LVEP91MNG |
ON Semiconductor |
Translation - Voltage Levels 2.5V/3.3V Any LVL to -2.5V/-3.3V/-5V NECL |
Data Sheet |
|
|
||||||||||||
