SN65HVD1050AQDRQ1

EMC optimized can transceiver, 8-SOIC, 4.75 V, 20 mA, SN65HVD1050AQDRQ1

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~0.24 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.15~0.24

PartNumber:: SN65HVD1050AQDRQ1

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Cheongtai's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-02-13

From Other Seller

Part Number:SN65HVD1050AQDRQ1
US $0.15 - 0.24
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN65HVD1050AQDRQ1 is an EMC optimized can transceiver. The device is also qualified for use in automotive applications in accordance with AEC-Q100. As a CAN transceiver, the SN65HVD1050AQDRQ1 provides differential transmit capability to the bus and differential receive capability to a CAN controller at signaling rates up to 1 megabit per second (Mbps). Applications of the SN65HVD1050AQDRQ1 include: Industrial Automation – DeviceNet Data Buses (Vendor ID #806); SAE J2284 High Speed CAN for Automotive Applications; SAE J1939 Standard Data Bus Interface; ISO 11783 Standard Data Bus Interface; NMEA 2000 Standard Data Bus Interface.

Parametrics

SN65HVD1050AQDRQ1 absolute maximum ratings: (1)VCC Supply voltage: –0.3 V to 7 V; (2)Voltage range at any bus terminal (CANH, CANL, Vref): –27 V to 40 V; (3)IO Receiver output current: 20 mA; (4)VI Voltage input, transient pulse (CANH, CANL): -200 V to 200 V; (5)VI Voltage input range (TXD, S): -0.5 V to 6 V; (6)TJ Junction temperature: –40℃ to 170℃.

Features

SN65HVD1050AQDRQ1 features: (1)Improved Replacement for the TJA1050; (2)High Electromagnetic Immunity (EMI); (3)Very Low Electromagnetic Emissions (EME); (4)Meets or Exceeds the Requirements of ISO 11898-2; (5)Bus-Fault Protection of –27 V to 40 V; (6)Dominant Time-Out Function; (7)Thermal Shutdown Protection; (8)Power-Up/Down Glitch-Free Bus Inputs and Outputs.
